Products introduction:

Nonghaha brand SD series winch type sprinkler is the only one machine in China which owns the full set Italy advanced technology, it can realize domestication products, build the most high-end sprinkler products at home, lead domestic sprinkler’s development trend. Its working principle is via immersible pump or booster pump produce high pressure water through the water pipe directly enter into the water turbine, high pressure water flow vertical impact impeller blade, strengthening the water turbine’s driving power, high pressure water flow through water turbine enter into PE pipe, at last enter to the spray gun then spray to the upper air, form wee droplets drop on the crops; recycling power adopts choking stream type water turbine produce strong power, via 6 gear reduction gear box drives winch rotation realize recycle PE pipe.

Products characteristic:

Winch recycle power

Adopts choking stream type water turbine driving, instead of side impact type water turbine structure, guarantee normal working under the lower water pressure(0.4Mpa); its working theory is high pressure water flow vertical impacting the impeller blade, water flow get the utmost of use, producing strong driving force, comparing with the side impacting type water turbine, in the same water pressure, the driving force can enhance 30%, spraying radius can enlarge 30% distance.

Speed gear box

Adopts 6 gears structure design(all is 2 gears in this business line), recycling speed adjusting range within 4-65m/h, meet various crops watering quantity; under the same power condition, 6 gears reduction gear box has smaller resistance than the 2 gears gear box, equivalently adding at least 20% recycling power.

Spray gun(matching double spray guns

Italy imported XIMEI brand impeller type spray guns, quality is stable and reliable, long using life; Atomization effect can be adjusted at random, without hurt on the crops plant, spraying uniformity is more than 95%

Domestic vertical swing arm spraying guns

Jet distance during spraying, strong wind resistance,guarantee the users can water the fields under the different weather condition.

Four wheel sprinkler wagon

Adopts four wheel walking structure, adding sprinkler wagon’s stability and loading; preventing the walking wheels sinking because of wet and soft surface soil, decreasing the waling resistance; the width of walking wheel is 8cm, decreasing grinding crops during working.

Sprinkler wagon lifting equipment

Sprinkler wagon recycles to the main body, handing the lifting equipment can rise the sprinkler wagon, heighten sprinkler wagon walking wheels ground clearance, it is convenient for the sprinkler’s movement and transportation; avoiding the walking wheels mop the ground during the machine is moving on some ditches and slops.

Transmission mode

Reduction gear box transmits power to winch is gear transmission, comparing with the chain transmission mode, gear transmission is more stable, without the problems of chain falling off, breaking or other situation.

Left and right supported feet

Adopts spiral vice-landing leg and lengthen pipe combine design, easy operation,fast, and convenient; powerful supporting, guarantee the main body’s stability when tract the sprinkler wagon.

Host walking tire

Big size with 10-12 tire, powerful carrying capacity and walking ability ,durable in use, reliable quality.

Host water entry

Adopts left and right side design, more convenient to link with the water delivery soft belt, avoiding the water delivery soft belt appears bend so that affects the passing ability of the high pressure water.

PE water pipe

Korea imported raw material, carrying water pressure is 1.6Mpa, reliable quality, weather resistance, maturing, using life is more than 15 years.

Optional equipment

Israel imported proportional fertilizer applicator

Realizing water and fertilizer integration working; high using ratio of the fertilizer, good absorption of the water and fertilizer, making sure the increasing crops quantity, saving time and labor. Fertilizing quantity range:10kg-1000kg/h, fertilizer amount is adjustable, high precision.

Dedicated spray irrigation frame

LG23/30 stainless steel dedicated spray irrigation frame,with 23 nozzles,30m spraying width, ground clearance 1.2-1.6m high, low pressure spraying work, without hurt to plants, watering quantity is 30-60ton/h; stainless steel material is corrosion prevention to the fertilizer, no rust occurred, long using life.
